15-9
Chapter 15: Appendix
15
[5] Configuration of local concentrations
In a location where several dozen devices are concentrated in close proximity, a network system can be
constructed using a star coupling hub.
An example of a configuration for a local concentration of devices
Hub
Star coupling hub
Twisted pair cable
[UTP: Category 5]
(Maximum cable
length 100 m)
