15-38
Chapter 15: Appendix
15
10BASE5 connector
(male)
LED10BASE-T connector
(female)
Coaxial cable
10BASE-T
Transceiver
Transceiver cable
(AUI cable)
(8) 10BASE5/10BASE-T converter
This converter is used to connect a 10BASE5 cable to a 10BASE-T cable.
10BASE5/10BASE-T converter for Ethernet use
Installation of a 10BASE5/10BASE-T converter for Ethernet use.
