User’s Guide 8-15

Offset Catch Tray

Accessories

Installing/Uninstalling the Offset Catch Tray

You can install an optional Offset Catch Tray to this printer.

Installing the Offset Catch Tray

1. Switch off the power to the printer.

2. Pull out the power cord from the power outlet and then the printer.

CAUTION: Be sure to switch off the power and unplug the power cord from the outlet before

carrying out the operations.
