10-8 User’s Guide

At the Duplex Module

Clearing Paper Jams

NOTE: Do not touch any parts inside the printer. Ensure that the Toner Cartridge is correctly installed.

7. Close the top cover securely.

At the Duplex Module

Duplex at the paper exit

1. Examine the paper exit and remove any jammed paper. If paper is torn, check for any

remaining torn pieces of paper.

NOTE: If the paper is difficult to remove, carry out the operation in the following section, See “Duplex at

the interior of the top cover” on page 10-9
