Press the [COLOR START] key ( ).
Copying will begin.
If you are using the document glass to copy multiple original
pages, copying will take place as you scan each original. If you
have selected sort mode, change originals and press the
[COLOR START] key ( ). Repeat until all pages have
been scanned and then touch the [Read-End] key.
To cancel scanning and copying...
Press the [STOP] key ( ).
To cancel a suppress background setting...
Touch the [Cancel] key in the screen of step 3.
