6 - 12
6
0: All inversion OFF
00
• Stop by origin signal
after origin proximity
escape
Origin proximity CW limit end
Origin signal
CCW
Start Stop
CW
CCW
Start Stop
CW
CCW
Start Stop
CW
Continued on the
following page
Results in a CW limit end error
Results in a CW limit end error
Results in a CW limit end error
Results in a CW limit end error
Origin proximity CW limit end
Origin signal
123
CCW
Start Stop
CW
CCW CW
CCW
Start
CW
Origin at 3rd count after deceleration
operation
Origin detection method
Zero return operation
*1
*2
01
• Origin count method 1
Deceleration
operation starts by
the edge of the
origin proximity
signal, and stops at
the determined
origin count after
escape from origin
proximity. In the
example on the
right, the count is
set to "3".
*1 Zero return operation: value of address A+0002 of parameter 1 (BCD: lower digit)
*2 Origin detection method: value of address A+0003 of parameter 1 (BCD: 2 digits)
Start Stop
Stop
[3] All inversion OFF
