Press the [COLOR START] key ( )
or the [BLACK & WHITE START] key
( ) to scan the first set of originals.
Scanning begins.
To cancel scanning...
Press the [STOP] key ( ).
4
Insert the next set of originals and press
the [COLOR START] key ( ) or the
[BLACK & WHITE START] key ( ).
Repeat this step until all originals have been scanned.
For the second set and following sets, use the same [START]
key as you did for the first set.
To cancel scanning...
Press the [STOP] key ( ). All scanned data will be cleared.
5
Touch the [Read-End] key.
To cancel copying...
Press the [STOP] key ( ).
If the Quick File Folder of document filing mode is full, copying in job build mode will be impeded. Delete unneeded files from
the Quick File Folder.
To cancel job build mode....
Touch the [Job Build] key in the screen of step 2 so that it is not highlighted.
or
or
Read-End
Place next original. Press [Start].
When finished, press [Read-End].
