Turn the card over and press the
[COLOR START] key ( ) or the
[BLACK & WHITE START] key ( ) to
scan the reverse side of the card.
Press the same [START] key that was used to scan the front
side.
Before scanning the back of the card, you can touch the [Configure] key in the touch panel to change the exposure.
To cancel scanning...
Press the [STOP] key ( ) to cancel the operation.
7
Touch the [Read-End] key.
If you will continue by scanning the front of the card, you can touch the [Configure] key to change the exposure,
resolution, scan size, and send size.
The ratio cannot be specified and "Rotation Sending Setting" cannot be selected.
To cancel Card Shot...
Touch the [Cancel] key in the screen of step 3.
or
Read-EndConfigure
Place next original. (Pg.No.x)
Press [Start].
When finished, press [Read-End].
