USING THE RESEND FUNCTION
The destinations of the most recent 8 transmissions by Scan to E-mail, Internet fax and/or fax are stored. One of these
can be selected to resend to that destination.
1
Touch the [Resend] key.
2
Touch the key of the desired address.
The last 8 addresses used for transmission are displayed.
• When the [Resend] key is touched and a destination selected, the mode of the selected destination is automatically
selected.
• The following types of addresses are not stored for resending.
• A one-touch key in which multiple destinations are stored (group key).
• Scan to FTP, Scan to Desktop, and Scan to Network Folder addresses.
• Broadcasting destinations
• Addresses used only for BCC delivery
• Destinations transmitted to using a program
Resend
Scan
Ready to send.
8½x11
USB Mem. ScanFaxInternet Fax PC Scan
File
Quick File
Address Review
Send Settings
Address Entry
Address Book
Auto Auto
Auto
Special Modes
Color Mode
File Format
Resolution
Exposure
Original
Scan: Send:
Text
200X200dpi
PDF
Auto/Grayscale
Mono2
PDF
Resend
Cancel
No.01
No.03
No.05
No.07
EEE EEE
CCC CCC
AAA AAA
GGG GGG
No.02
No.04
No.06
No.08
FFF FFF
DDD DDD
BBB BBB
HHH HHH
