Touch the [OK] key.
The specified size appears in the [Scan Size] key.
• When the scan size is specified by numerical values, the send size cannot be specified.
• When the automatic document feeder is used, an original longer that 17" (432 mm) can be scanned (maximum width
31-1/2" (800 mm)). In this case, touch the [Long Size] key in the screen of step 3.
☞ Specifying the original scan size (by paper size) (page 46)
Auto
X17 Y11
Scan Size Send Size
Fax/Original
OK
2-Sided
Booklet
2-Sided
Tablet
Image Orientation
