WHITENING FAINT COLORS IN THE IMAGE
(Suppress Background)
This feature is used to suppress light background areas.
• This function cannot be used in Internet fax mode.
• When using USB memory mode, connect the USB memory device to the machine before performing the procedure below.
1
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
2
Select the special modes.
(1) Touch the tab of the mode that you wish to use.
(2) Touch the [Special Modes] key.
(3) Touch the [Suppress Background] key.
Read the message that appears and then touch the [OK] key.
☞ SPECIAL MODES (page 70)
3
Select the suppress background setting.
(1) Adjust the background suppression level.
Touch the [+] key to suppress only faint background.
Touch the [-] key to suppress faint to dark background.
(2) Touch the [OK] key.
The lightness level at which
suppression takes place
can be adjusted.
Level [+]
Level [-]
Scan/Special Modes
OK
Suppress Background
Light areas of the original may be suppressed as background.
OKCancel
1
3
(1) (2)
