122
ADJUSTING THE COLOR (Color Balance)
The color, tone, and density of color copies can be adjusted.
Each of the colors yellow, cyan, magenta, and black are
divided into 8 gradations from light to dark, and the
average density of each gradation can be adjusted,
or all eight gradations can be adjusted at once.
OK
OK
Cancel
Color Adjustments
Color Balance
Y
M
C
Bk
1 2 3 4 5 6 7 8
All
12345678
Dark
Light
C Cyan+ M Magenta+
Y Yellow+ B Black+
1
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
2
Select the special modes.
(1) Touch the [Special Modes] key.
(2) Touch the keys to switch through the screens.
(3) Touch the [Color Adjustments] key.
(4) Touch the [Color Balance] key.
☞ [Color Adjustments] KEY (page 117)
