Sharp VL-E40S Informazioni Techniche Pagina 100
- Pagina / 158
- Indice
- SEGNALIBRI
Valutato. / 5. Basato su recensioni clienti
ForThinkPadEdge14"andE40:
2 3
5
6
7
89
10
12
11
41
2010LCDfrontbezel
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
•“1150LCDunit”onpage79
RemovalstepsoftheLCDfrontbezel
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×5mm,wafer-head,nylon-coated(4),withrubbercaps
Black0.181Nm
(1.85kgf-cm)
94HardwareMaintenanceManual
- HardwareMaintenanceManual 1
