ForThinkPadEdge14"andE40:
1190DC-incableandbasecover
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1020Opticaldriveortravelcover”onpage58
•“1030Thermalcover”onpage59
•“1040Harddiskdriveassembly”onpage60
•“1050Memorymodule”onpage61
•“1060Fanassembly”onpage62
•“1070Microprocessor”onpage65
•“1080WirelessWANslotcoverandPCIExpressMiniCardforwirelessWAN”onpage66
•“1090Palmrestassemblywithcables”onpage69
•“1100PCIExpressMiniCardforwirelessLAN”onpage72
•“1110Backupbattery”onpage74
•“1120Bluetoothdaughtercard”onpage74
•“1130Keyboard”onpage75
•“1140Keyboardbezel”onpage77
•“1150LCDunit”onpage79
•“1160Topshieldingassembly”onpage82
•“1170Systemboardassembly”onpage84
90HardwareMaintenanceManual
