Chapter9.Locations
ThischapterpresentsthelocationofThinkPadEdge14",Edge15",E40,andE50featuresandhardware.
Frontview
1
Integratedcamera
2
Built-inmicrophone
3
Built-instereospeakers
4
Powerswitch
5
Securitykeyhole
6
Powerstatusindicator
Note:Forthedescriptionoftheindicator,seeChapter5“Statusindicators”onpage49
.
7
ACpowerconnector
8
Opticaldriveortravelcover
9
Universalserialbus(USB)connectors
10
Sleep(standby)statusindicator
Note:Forthedescriptionoftheindicator,seeChapter5“Statusindicators”onpage49.
11
Fingerprintreader(forsomemodels)
12
Touchpadbuttons
13
Touchpad
14
TrackPointbuttons
15
TrackPointpointingstick
16
UltraNav
®
