Removalstepsofthetopshieldingassembly
ForThinkPadEdge15"andE50:
1
2
2
2
2
2
3
3
4
StepScrew(quantity)Color
Torque
1
M2×2mm,wafer-head,nylon-coated(3)Silver
0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(5)
Black0.181Nm
(1.85kgfcm)
3
M2×5mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgfcm)
Chapter8.RemovingorreplacingaFRU83
