Thefollowinglabelsneedtobepeeledofffromtheoldbasecover,andneedtobeputonthenewbasecover.
1
MACaddresslabel
2
WirelessWANMACaddresslabel
5
Serialnumberlabel
7
FFClabel
8
SIRMlabel
9
SIMICCIDlabel
10
BrazilAnatelBGlabel
11
Israellabel(SIMmodel)
12
BrazilAnatelBluetoothlabel
Forsomemodels,youalsoneedtoapplyoneortwoFCClabels.Checktheoldbasecover;ifithasoneor
twoFCClabels,ndduplicatesoftheminthelabelkitandapplythemtothenewbasecover.
Forthelocationofeachlabel,refertothefollowinggures:
ForThinkPadEdge15"andE50:
2 3
89
41
5
6
7
10
12
11
Chapter8.RemovingorreplacingaFRU93
