Removalstepsoftheantennaassembly
ReleasetheantennacablesfromthecableguidesoftheLCDrearcoverassemblyandfromthehinges.
1
2 2
1
1
1
1
1
1
1
Wheninstalling:Routethecablesasshowninthisgure.Whenyouroutethecables,makesurethatthey
arenotsubjectedtoanytension.Tensioncouldcausethecablestobedamagedbythecableguides,
orawiretobebroken.
