Chapter8.RemovingorreplacingaFRU

ExternalCRUstatementtocustomers:

Someproblemswithyourproductcanberesolvedwithareplacementpartyoucaninstallyourself,called

a“CustomerReplaceableUnit”or“CRU.”SomeCRUsaredesignatedasSelf-serviceCRUsandothers

aredesignatedasOptional-serviceCRUs.InstallationofSelf-serviceCRUsisyourresponsibility;youmay

requestthatLenovoinstallsanOptional-serviceCRUaccordingtothewarrantyserviceforyourproduct.

WhereyouareinstallingtheCRU,LenovowillshiptheCRUtoyou.CRUinformationandreplacement

instructionsareshippedwithyourproductandareavailablefromLenovoatanytimeuponrequest.Y oumay

ndalistofCRUsinthepublicationsthatshipwithyourproductorathttp://www.lenovo.com/CRUs.Y ou

mayberequiredtoreturnthedefectivepartthatisreplacedbytheCRU.Whenreturnisrequired:(1)return

instructions,aprepaidshippinglabel,andacontainerwillbeincludedwiththereplacementCRU;and(2)you

maybechargedforthereplacementCRUifLenovodoesnotreceivethedefectivepartwithinthirty(30)days

ofyourreceiptofthereplacementCRU.SeeyourLenovoLimitedWarrantydocumentationforfulldetails.

ThischapterpresentsdirectionsanddrawingsforuseinremovingandreplacingaFRU.Besuretoobserve

thefollowinggeneralrules:

1.Donottrytoserviceanycomputerunlessyouhavebeentrainedandcertied.Anuntrainedpersonruns

theriskofdamagingparts.

2.BeforereplacinganyFRU,reviewChapter7“FRUreplacementnotices”onpage53.

3.BeginbyremovinganyFRUsthathavetoberemovedbeforethefailingFRU.AnysuchFRUsarelisted

atthetopofthepage.Removethemintheorderinwhichtheyarelisted.

4.FollowthecorrectsequenceinthestepsforremovingtheFRU,asgiveninthedrawingsbythe

numbersinsquarecallouts.

5.WhenturningascrewtoreplaceaFRU,turnitinthedirectionasgivenbythearrowinthedrawing.

6.WhenremovingtheFRU,moveitinthedirectionasgivenbythearrowinthedrawing.

7.ToputthenewFRUinplace,reversetheremovalprocedureandfollowanynotesthatpertainto

replacement.Forinformationaboutconnectingandarranginginternalcables,seeChapter9“Locations”

onpage101.

8.WhenreplacingaFRU,usethecorrectscrewasshownintheprocedures.

DANGER

BeforeremovinganyFRU,turnoffthecomputer,unplugallpowercordsfromelectricaloutlets,

removethebatterypack,andthendisconnectanyinterconnectingcables.

Attention:AfterreplacingaFRU,donotturnonthecomputeruntilyouhavemadesurethatallscrews,

springs,andothersmallpartsareinplaceandnonearelooseinsidethecomputer.Verifythisbyshaking

thecomputergentlyandlisteningforrattlingsounds.Metallicpartsormetalakescancauseelectrical

shortcircuits.

Attention:Thesystemboardissensitiveto,andcanbedamagedby,electrostaticdischarge.Before

touchingit,establishpersonalgroundingbytouchingagroundpointwithonehandorbyusingan

electrostaticdischarge(ESD)strap(P/N6405959).
