Removalstepsofthethermalcover
Loosenthescrews1,butdonotremovethem.
1
1
1
1
1
2
Attention:Donottouchorapplyanyexcessiveforcetothefanmotorlocatedintheslot.Itmightcausedamage
tothefanassemblyorthecomputertomulfunction.
1040Harddiskdriveassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage58
•“1030Thermalcover”onpage59
Attention:
•Donotdropthedriveorapplyanyphysicalshocktoit.Thedriveissensitivetophysicalshock.
Improperhandlingcancausedamageandpermanentlossofdata.
•Beforeremovingthedrive,havetheusermakeabackupcopyofalltheinformationonitifpossible.
•Neverremovethedrivewhilethecomputerisoperatingorisinsuspendmode.
60HardwareMaintenanceManual
