Seeger-Ringe für Bohrungen
Seeger-Rings for bores
Segments intérieurs Seeger
Seeger-Ringe für Bohrungen
Seeger-Rings for bores
Segments intérieurs Seeger
38 39
11
Maßliste Standard
Data chart Standard
Table Exécution
dimensionnelle standard
Nennmaß
Nominal
dimension
Dimension
nominale
Toleranz Toleranz Gew.
Tolerance Tolerance a b d
5
Weight
Tolérance Tolérance Masse
d
1
sd
3
max. ≈ min. kg/1000
Bezeichnung
Designation
Désignation
Bestell-Nummer
Order number
Référence
de commande
11
Nut · Groove · Gorge Ergänzende Daten · Supplementary data · Données complémentaires
Toleranz Zange
Tolerance m* F
N
F
R
F
Rg
A
N
K nabl. Pliers
d
2
* Tolérance min. t n kN kN g kN mm
2
kN · mm x1000 Pince
* Siehe Abschnitt 8, Seite 128 · * See section 8, page 128 · * Voir paragraphe 8, page 128
J 252 – J 450 / DIN 472
J 252 – J 450 / DIN 472
Ring, Ring, Anneau
Ungespannt
Unstressed
A l’état libre
nach Wahl des
Herstellers
manufacturer’s
choice
suivant les disponibilités
du fabricant
J 252 J252–WAS 252 5,00 – 0,12 262,0 + 2,00 – 0,81 14,2 16,0 5,0 360,00 260,0 + 0,81 5,15 4,00 12,0 535,00 557,0 4,0 83,0 3215,0
J 255 J255–WAS 255 5,00 – 0,12 270,0 + 2,00 – 0,81 16,2 16,0 5,0 368,00 263,0 + 0,81 5,15 4,00 12,0 541,00 549,0 4,0 81,5 3250,0
J 257 J255–WAS 257 5,00 – 0,12 270,0 + 2,00 – 0,81 16,2 16,0 5,0 368,00 265,0 + 0,81 5,15 4,00 12,0 546,00 545,0 4,0 81,0 3280,0
J 258 J260–WAS 258 5,00 – 0,12 275,0 + 2,00 – 0,81 16,2 16,0 5,0 375,00 266,0 + 0,81 5,15 4,00 12,0 548,00 543,0 4,0 80,5 3290,0
J 260 J260–WAS 260 5,00 – 0,12 275,0 + 2,00 – 0,81 16,2 16,0 5,0 375,00 268,0 + 0,81 5,15 4,00 12,0 553,00 538,0 4,0 80,0 3320,0
J 262 J260–WAS 262 5,00 – 0,12 275,0 + 2,00 – 0,81 16,2 16,0 5,0 375,00 270,0 + 0,81 5,15 4,00 12,0 556,00 535,0 4,0 79,0 3340,0
J 265 J265–WAS 265 5,00 – 0,12 280,0 + 2,00 – 0,81 16,2 16,0 5,0 383,00 273,0 + 0,81 5,15 4,00 12,0 563,00 528,0 4,0 78,5 3380,0
J 267 J265–WAS 267 5,00 – 0,12 280,0 + 2,00 – 0,81 16,2 16,0 5,0 383,00 275,0 + 0,81 5,15 4,00 12,0 566,00 524,0 4,0 78,0 3400,0
J 268 J270–WAS 268 5,00 – 0,12 285,0 + 2,00 – 0,81 16,2 16,0 5,0 388,00 276,0 + 0,81 5,15 4,00 12,0 570,00 522,0 4,0 77,5 3420,0
J 270 J270–WAS 270 5,00 – 0,12 285,0 + 2,00 – 0,81 16,2 16,0 5,0 388,00 278,0 + 0,81 5,15 4,00 12,0 573,00 518,0 4,0 77,0 3440,0
J 272 J270–WAS 272 5,00 – 0,12 285,0 + 2,00 – 0,81 16,2 16,0 5,0 388,00 280,0 + 0,81 5,15 4,00 12,0 577,00 515,0 4,0 76,5 3465,0
J 275 J275–WAS 275 5,00 – 0,12 290,0 + 2,00 – 0,81 16,2 16,0 5,0 393,00 283,0 + 0,81 5,15 4,00 12,0 585,00 509,0 4,0 75,5 3510,0
J 277 J275–WAS 277 5,00 – 0,12 290,0 + 2,00 – 0,81 16,2 16,0 5,0 393,00 285,0 + 0,81 5,15 4,00 12,0 587,00 505,0 4,0 75,0 3525,0
J 278 J280–WAS 278 5,00 – 0,12 295,0 + 2,00 – 0,81 16,2 16,0 5,0 400,00 286,0 + 0,81 5,15 4,00 12,0 590,00 504,0 4,0 75,0 3540,0
J 280 J280–WAS 280 5,00 – 0,12 295,0 + 2,00 – 0,81 16,2 16,0 5,0 400,00 288,0 + 0,81 5,15 4,00 12,0 593,00 499,0 4,0 74,0 3560,0
J 282 J280–WAS 282 5,00 – 0,12 295,0 + 2,00 – 0,81 16,2 16,0 5,0 400,00 290,0 + 0,81 5,15 4,00 12,0 599,00 497,0 4,0 74,0 3595,0
J 285 J285–WAS 285 5,00 – 0,12 300,0 + 2,00 – 0,81 16,2 16,0 5,0 408,00 293,0 + 0,81 5,15 4,00 12,0 605,00 491,0 4,0 73,0 3630,0
J 287 J285–WAS 287 5,00 – 0,12 300,0 + 2,00 – 0,81 16,2 16,0 5,0 408,00 295,0 + 0,81 5,15 4,00 12,0 610,00 487,0 4,0 72,0 3660,0
J 288 J290–WAS 288 5,00 – 0,12 305,0 + 2,00 – 0,81 16,2 16,0 5,0 415,00 296,0 + 0,81 5,15 4,00 12,0 611,00 485,0 4,0 72,0 3670,0
J 290 J290–WAS 290 5,00 – 0,12 305,0 + 2,00 – 0,81 16,2 16,0 5,0 415,00 298,0 + 0,81 5,15 4,00 12,0 615,00 482,0 4,0 71,5 3695,0
J 292 J290–WAS 292 5,00 – 0,12 305,0 + 2,00 – 0,81 16,2 16,0 5,0 415,00 300,0 + 0,81 5,15 4,00 12,0 620,00 479,0 4,0 71,0 3720,0
J 295 J295–WAS 295 5,00 – 0,12 310,0 + 2,00 – 0,81 16,2 16,0 5,0 426,00 303,0 + 0,81 5,15 4,00 12,0 625,00 474,0 4,0 70,5 3755,0
J 297 J295–WAS 297 5,00 – 0,12 310,0 + 2,00 – 0,81 16,2 16,0 5,0 426,00 305,0 + 0,81 5,15 4,00 12,0 630,00 471,0 4,0 70,5 3780,0
J 298 J300–WAS 298 5,00 – 0,12 315,0 + 2,00 – 0,81 16,2 16,0 5,0 435,00 306,0 + 0,81 5,15 4,00 12,0 631,00 469,0 4,0 69,5 3790,0
J 300 J300–WAS 300 5,00 – 0,12 315,0 + 2,00 – 0,81 16,2 16,0 5,0 435,00 308,0 + 0,81 5,15 4,00 12,0 636,00 466,0 4,0 69,0 3820,0
J 305 J305–XLS 305 6,00 – 0,15 322,0 + 2,00 – 0,90 20,0 6,0 755,00 315,0 + 0,81 6,20 5,00 15,0 810,00 961,0 5,0 114,0 4860,0
J 310 J310–XLS 310 6,00 – 0,15 327,0 + 2,00 – 0,90 20,0 6,0 770,00 320,0 + 0,89 6,20 5,00 15,0 823,00 947,0 5,0 113,0 4940,0
J 315 J315–XLS 315 6,00 – 0,15 332,0 + 2,00 – 0,90 20,0 6,0 785,00 325,0 + 0,89 6,20 5,00 15,0 837,00 934,0 5,0 111,0 5027,0
J 320 J320–XLS 320 6,00 – 0,15 337,0 + 2,00 – 0,90 20,0 6,0 800,00 330,0 + 0,89 6,20 5,00 15,0 850,00 919,0 5,0 109,0 5100,0
J 325 J325–XLS 325 6,00 – 0,15 342,0 + 2,00 – 0,90 20,0 6,0 810,00 335,0 + 0,89 6,20 5,00 15,0 864,00 906,0 5,0 108,0 5184,0
J 330 J330–XLS 330 6,00 – 0,15 347,0 + 2,00 – 0,90 20,0 6,0 820,00 340,0 + 0,89 6,20 5,00 15,0 876,00 894,0 5,0 106,0 5260,0
J 335 J335–XLS 335 6,00 – 0,15 352,0 + 2,00 – 0,90 20,0 6,0 830,00 345,0 + 0,89 6,20 5,00 15,0 890,00 880,0 5,0 105,0 5341,0
J 340 J340–XLS 340 6,00 – 0,15 357,0 + 2,00 – 0,90 20,0 6,0 840,00 350,0 + 0,89 6,20 5,00 15,0 903,00 869,0 5,0 104,0 5420,0
J 345 J345–XLS 345 6,00 – 0,15 362,0 + 2,00 – 0,90 20,0 6,0 855,00 355,0 + 0,89 6,20 5,00 15,0 916,00 857,0 5,0 102,0 5498,0
J 350 J350–XLS 350 6,00 – 0,15 367,0 + 2,00 – 0,90 20,0 6,0 870,00 360,0 + 0,89 6,20 5,00 15,0 929,00 846,0 5,0 101,0 5575,0
J 355 J355–XLS 355 6,00 – 0,15 372,0 + 2,00 – 0,90 20,0 6,0 880,00 365,0 + 0,89 6,20 5,00 15,0 942,00 834,0 5,0 99,0 5655,0
J 360 J360–XLS 360 6,00 – 0,15 377,0 + 2,00 – 0,90 20,0 6,0 890,00 370,0 + 0,89 6,20 5,00 15,0 955,00 823,0 5,0 98,0 5730,0
J 365 J365–XLS 365 6,00 – 0,15 382,0 + 2,00 – 0,90 20,0 6,0 906,00 375,0 + 0,89 6,20 5,00 15,0 968,00 813,0 5,0 97,0 5812,0
J 370 J370–XLS 370 6,00 – 0,15 387,0 + 2,00 – 0,90 20,0 6,0 920,00 380,0 + 0,89 6,20 5,00 15,0 981,00 803,0 5,0 95,0 5890,0
J 375 J375–XLS 375 6,00 – 0,15 392,0 + 2,00 – 0,90 20,0 6,0 932,00 385,0 + 0,89 6,20 5,00 15,0 994,00 793,0 5,0 94,0 5969,0
J 380 J380–XLS 380 6,00 – 0,15 397,0 + 2,00 – 0,90 20,0 6,0 940,00 390,0 + 0,89 6,20 5,00 15,0 1008,00 784,0 5,0 93,0 6050,0
J 385 J385–XLS 385 6,00 – 0,15 402,0 + 2,00 – 1,00 20,0 6,0 950,00 395,0 + 0,89 6,20 5,00 15,0 1021,00 774,0 5,0 92,0 6126,0
J 390 J390–XLS 390 6,00 – 0,15 407,0 + 2,00 – 1,00 20,0 6,0 960,00 400,0 + 0,89 6,20 5,00 15,0 1033,00 764,0 5,0 91,0 6200,0
J 395 J395–XLS 395 6,00 – 0,15 412,0 + 2,00 – 1,00 20,0 6,0 972,00 405,0 + 1,00 6,20 5,00 15,0 1047,00 756,0 5,0 90,0 6283,0
J 400 J400–XLS 400 6,00 – 0,15 417,0 + 2,00 – 1,00 20,0 6,0 980,00 410,0 + 1,00 6,20 5,00 15,0 1060,00 746,0 5,0 89,0 6360,0
J 410 J410–XLS 410 7,00 – 0,15 430,0 + 2,00 – 1,00 26,0 6,0 1380,00 422,0 + 1,00 7,20 6,00 18,0 1307,00 1512,0 6,0 150,0 7842,0
J 420 J420–XLS 420 7,00 – 0,15 440,0 + 2,00 – 1,00 26,0 6,0 1410,00 432,0 + 1,00 7,20 6,00 18,0 1338,00 1480,0 6,0 147,0 8030,0
J 430 J430–XLS 430 7,00 – 0,15 450,0 + 2,00 – 1,00 26,0 6,0 1440,00 442,0 + 1,00 7,20 6,00 18,0 1369,00 1446,0 6,0 144,0 8219,0
J 440 J440–XLS 440 7,00 – 0,15 460,0 + 2,00 – 1,00 26,0 6,0 1470,00 452,0 + 1,00 7,20 6,00 18,0 1401,00 1418,0 6,0 141,0 8407,0
J 450 J450–XLS 450 7,00 – 0,15 470,0 + 2,00 – 1,00 26,0 6,0 1510,00 462,0 + 1,00 7,20 6,00 18,0 1431,00 1388,0 6,0 138,0 8590,0
1277,0 ZGJ-6
1259,0 ZGJ-6
1249,0 ZGJ-6
1244,0 ZGJ-6
1234,0 ZGJ-6
1227,0 ZGJ-6
1210,0 ZGJ-6
1201,0 ZGJ-6
1196,0 ZGJ-6
1188,0 ZGJ-6
1180,0 ZGJ-6
1167,0 ZGJ-6
1158,0 ZGJ-6
1154,0 ZGJ-6
1145,0 ZGJ-6
1138,0 ZGJ-6
1124,0 ZGJ-6
1117,0 ZGJ-6
1111,0 ZGJ-6
1104,0 ZGJ-6
1098,0 ZGJ-6
1087,0 ZGJ-6
1079,0 ZGJ-6
1075,0 ZGJ-6
1068,0 ZGJ-6
2202,0 ZGJ-6
2169,0 ZGJ-6
2140,0 ZGJ-6
2105,0 ZGJ-6
2076,0 ZGJ-6
2048,0 ZGJ-6
2017,0 ZGJ-6
1991,0 ZGJ-6
1964,0 ZGJ-6
1938,0 ZGJ-6
1910,0 ZGJ-6
1886,0 ZGJ-6
1862,0 ZGJ-6
1839,0 ZGJ-6
1817,0 ZGJ-6
1796,0 ZGJ-6
1774,0 ZGJ-6
1751,0 ZGJ-6
1732,0 ZGJ-6
1710,0 ZGJ-6
3463,0 ZGJ-7
3391,0 ZGJ-7
3312,0 ZGJ-7
3248,0 ZGJ-7
3180,0 ZGJ-7
