Seeger-Stützscheiben
Seeger Support Washers
Rondelles d’appui Seeger
96
61
Maßliste Standard
Data chart Standard
Table Exécution
dimensionnelle standard
Gew.
Toleranz Weight
d D S Tolerance Masse
Tolérance kg/1000
Bezeichnung
Designation
Désignation
Bestell-Nummer
Order number
Référence
de commande
SS 3 – SS 95 / DIN 988
Dicke
Thickness
Epaisseur
SS 3 x 6x 1,0 SS003006100–BLS 3 6 1,0 – 0,05 0,165
SS 4 x 8 x 1,0 SS004008100–BLS 4 8 1,0 – 0,05 0,296
SS 5 x 10x 1,0 SS005010100–BLS 5 10 1,0 – 0,05 0,462
SS 6 x 12x 1,2 SS006012120–BLS 6 12 1,2 – 0,05 0,800
SS 7 x 13x 1,2 SS007013120–BLS 7 13 1,2 – 0,05 0,885
SS 8 x 14x 1,2 SS008014120–BLS 8 14 1,2 – 0,05 0,980
SS 9 x 15x 1,2 SS009015120–BLS 9 15 1,2 – 0,05 1,070
SS 10 x 16x 1,2 SS010016120–BLS 10 16 1,2 – 0,05 1,150
SS 11 x 17 x 1,2 SS011017120–BLS 11 17 1,2 – 0,05 1,233
SS 12 x 18x 1,2 SS012018120–BLS 12 18 1,2 – 0,05 1,330
SS 13 x 19x 1,5 SS013019150–BLS 13 19 1,5 – 0,05 1,780
SS 14 x 20x 1,5 SS014020150–BLS 14 20 1,5 – 0,05 1,890
SS 15 x 21x 1,5 SS015021150–BLS 15 21 1,5 – 0,05 2,000
SS 15 x 22x 1,5 SS015022150–BLS 15 22 1,5 – 0,05 2,050
SS 16 x 22x 1,5 SS016022150–BLS 16 22 1,5 – 0,05 2,100
SS 17 x 24x 1,5 SS017024150–BLS 17 24 1,5 – 0,05 2,650
SS 18 x 25x 1,5 SS018025150–BLS 18 25 1,5 – 0,05 2,780
SS 19 x 26x 1,5 SS019026150–BLS 19 26 1,5 – 0,05 2,910
SS 20 x 28x 2,0 SS020028200–BLS 20 28 2,0 – 0,05 4,720
SS 22 x 30x 2,0 SS022030200–BLS 22 30 2,0 – 0,05 5,140
SS 22 x 32x 2,0 SS022032200–BLS 22 32 2,0 – 0,05 6,660
SS 25 x 35x 2,0 SS025035200–BLS 25 35 2,0 – 0,05 7,400
SS 25 x 36x 2,0 SS025036200–BLS 25 36 2,0 – 0,05 8,280
SS 26 x 37x 2,0 SS026037200–BLS 26 37 2,0 – 0,05 8,540
SS 28 x 40x 2,0 SS028040200–BLS 28 40 2,0 – 0,05 10,060
SS 30 x 42x 2,5 SS030042250–S 30 42 2,5 – 0,05 13,400
SS 32 x 45x 2,5 SS032045250–S 32 45 2,5 – 0,05 15,500
SS 35 x 45x 2,5 SS035045250–S 35 45 2,5 – 0,05 12,300
SS 36 x 45x 2,5 SS036045250–S 36 45 2,5 – 0,05 11,300
SS 37 x 47x 2,5 SS037047250–S 37 47 2,5 – 0,05 12,900
SS 40 x 50x 2,5 SS040050250–S 40 50 2,5 – 0,05 13,900
SS 42 x 52x 2,5 SS042052250–S 42 52 2,5 – 0,05 14,500
SS 45 x 55x 3,0 SS045055300–S 45 55 3,0 – 0,06 18,600
SS 45 x 56x 3,0 SS045056300–S 45 56 3,0 – 0,06 20,400
SS 48 x 60x 3,0 SS048060300–S 48 60 3,0 – 0,06 23,700
SS 50 x 62 x 3,0 SS050062300–S 50 62 3,0 – 0,06 24,900
SS 50 x 63x 3,0 SS050063300–S 50 63 3,0 – 0,06 27,300
SS 52 x 65 x 3,0 SS052065300–S 52 65 3,0 – 0,06 28,200
SS 55 x 68x 3,0 SS055068300–S 55 68 3,0 – 0,06 29,300
SS 56 x 70x 3,0 SS056070300–S 56 70 3,0 – 0,06 32,700
SS 56 x 72x 3,0 SS056072300–S 56 72 3,0 – 0,06 38,000
SS 60 x 75x 3,0 SS060075300–S 60 75 3,0 – 0,06 37,500
SS 63 x 80x 3,0 SS063080300–S 63 80 3,0 – 0,06 45,000
SS 65 x 85x 3,5 SS065085350–S 65 85 3,5 – 0,06 63,000
SS 70 x 90x 3,5 SS070090350–S 70 90 3,5 – 0,06 69,000
SS 75 x 95 x 3,5 SS075095350–S 75 95 3,5 – 0,06 73,200
SS 80 x 100 x 3,5 SS080100350–S 80 100 3,5 – 0,06 77,800
SS 85 x 105 x 3,5 SS085105350–S 85 105 3,5 – 0,06 82,000
SS 90 x 110 x 3,5 SS090110350–S 90 110 3,5 – 0,06 86,500
SS 95 x 115 x 3,5 SS095115350–S 95 115 3,5 – 0,06 90,700
Durchmesser
Diameter
Diamètre
Seeger-Stützscheiben
Seeger Support Washers
Rondelles d’appui Seeger
61
Maßliste Standard
Data chart Standard
Table Exécution
dimensionnelle standard
Gew.
Toleranz Weight
d D S Tolerance Masse
Tolérance kg/1000
Bezeichnung
Designation
Désignation
Bestell-Nummer
Order number
Référence
de commande
SS 100 – SS 170 / DIN 988
Dicke
Thickness
Epaisseur
Durchmesser
Diameter
Diamètre
SS 100x 120 x 3,5 SS100120350–WAS 100 120 3,5 – 0,06 95,200
SS 100 x 125 x 3,5 SS100125350–WAS 100 125 3,5 – 0,08 122,000
SS 105 x 130 x 3,5 SS105130350–WAS 105 130 3,5 – 0,08 127,000
SS 110 x 140 x 3,5 SS110140350–WAS 110 140 3,5 – 0,08 162,000
SS 120 x 150 x 3,5 SS120150350–WAS 120 150 3,5 – 0,08 175,000
SS 130 x 160 x 3,5 SS130160350–WAS 130 160 3,5 – 0,08 188,000
SS 140 x 170 x 3,5 SS140170350–WAS 140 170 3,5 – 0,08 201,000
SS 150 x 180 x 3,5 SS150180350–WAS 150 180 3,5 – 0,08 214,000
SS 160 x 190 x 3,5 SS160190350–WAS 160 190 3,5 – 0,08 227,000
SS 170 x 200 x 3,5 SS170200350–WAS 170 200 3,5 – 0,08 240,000
