16. FULLY CLOSED LOOP SYSTEM (available in the future)
16 - 17
16.3.3 Operation from controller
The fully closed loop control compatible servo amplifier can be used with any of the following controllers.
%CVGIQT[
/QFGN
4GOCTMU
Motion controller Q17nDSCPU
Simple motion module QD77MS_
Speed control (II) instructions (VVF and VVR) cannot
be used.
An absolute type linear encoder is necessary to configure an absolute position detection system under fully
closed loop control using a linear encoder. In this case, the encoder battery (MR-BAT6V1SET) need not be
installed to the servo amplifier. When an rotary encoder is used, an absolute position detection system can
be configured by installing the encoder battery (MR-BAT6V1SET) to the servo amplifier. In this case, the
battery life will be shorter because the power consumption is increased as the power is supplied to the two
encoders of motor side and load side.
(1) Operation from controller
Positioning operation from the controller is basically performed like the semi closed loop control.
(2) Servo system controller setting
When using fully closed loop system, make the following setting.
[[Pr.PA01], [Pr.PC17], [Pr.PE01], [Pr.PE03] to [Pr.PE05], [Pr.PE34] and [Pr.PE35] are written to the
servo amplifier and then are enabled using any of the methods indicated by ż in Parameter valid
conditions. [Pr. PE06] to [Pr. PE08] are enabled at setting regardless of the valid conditions.
Parameter valid
conditions
Settings
Motion
controller
Simple motion
module
Setting item
Controller
reset
Power
supply
Offĺon
Q17nDSCPU QD77MS_
Command
resolution
Load-side encoder resolution
unit
MR-J4-B fully closed loop servo amplifier setting MR-J4-B fully closed loop controlServo
parameter
Motor setting Automatic setting
Home position setting condition selection ([Pr. PC17])
Set the items as required.
Fully closed loop selection ([Pr. PA01] and [Pr. PE01])
Fully closed loop selection 2 ([Pr. PE03])
Fully closed loop control error detection speed deviation
error detection level
([Pr. PE06])
Valid at setting
regardless of the valid
conditions
⸳ቯᤨߦല
Fully closed loop control error detection position
deviation error detection level
([Pr. PE07])
Fully closed loop electronic gear numerator ([Pr. PE04]
and [Pr. PE34])
Fully closed loop electronic gear denominator ([Pr. PE05]
and [Pr. PE35])
Fully closed loop dual feedback filter ([Pr. PE08]) Valid at setting
regardless of the valid
conditions
⸳ቯᤨߦല
Unit setting mm/inch/degree/pulse Positioning
control
parameter
ᓮ↪
ࡄࡔ࠲
Number of pulses per revolution (AP)
Travel distance per revolution (AL)
For the setting methods, refer to (2) (a), (b) in this section.
