APPENDIX
App. - 2
(c) New handling label design containing battery illustration must be used. (only air transportation)
Figure. Example of Mitsubishi Label with Battery Illustration
(4) Action taken by Mitsubishi
The following caution will be added to the packages of the target batteries.
"Containing lithium metal battery. Regulations apply for transportation."
(5) Transportation precaution for customers
For sea or air transportation, attaching the handling label (figure) and the Shipper's Declaration for
Dangerous Goods are required to the package of a Mitsubishi cell or battery. In addition, attaching them
to the outer package containing several packages of Mitsubishi cells or batteries are also required.
Please attach the documentations in the specified design to the packages and the outer packages.
