3.13 Hard Disk Test 3 Tests and Diagnostics
3-30 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
Subtest 04 Cross talk & peak shift
This subtest writes eight types of worst pattern data (listed below) to a cylinder,
then reads the data while moving from cylinder to cylinder. (Test the data
interference in the neighbor track)
Worst pattern data Cylinder
‘B5ADAD’ 0 cylinder
‘4A5252’ 1 cylinder
‘EB6DB6’ 2 cylinder
‘153449’ 3 cylinder
’63B63B’ 4 cylinder
‘9C49C4’ 5 cylinder
‘2DB6DB’ 6 cylinder
‘D25344’ 7 cylinder
Subtest 05 Partial Read
This subtest reads 1GB data that is in minimum, middle and maximum address of
the HDD area.
Subtest 06 Write specified address
This subtest writes specified data to a specified cylinder and head on the HDD.
Subtest 07 Read specified address
This subtest reads data, which has been written to a specified cylinder and head on
the HDD.
Subtest 08 Sequential write
This subtest writes specified 2-byte data to all of the cylinders on the HDD.
Subtest 09 W-R-C specified address
This subtest writes data to a specified cylinder and head on the HDD, then reads
the data and compares it to the original data.
