4 Replacement Procedures 4.18 Battery Lock
4-54 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
Installing the Battery lock
The following describes the procedure for installing the battery latch (See Figure 4-37, 4-38).
1. Set the spring to the battery lock R and install it on the base assembly.
2. Install the battery lock button from the bottom of the base assembly and snap their
projections to the battery lock R. When installing the button, make sure the mark
on the back side is located in the indicated position. After installation, slide the latch
on the bottom of the base assembly to make sure it works properly.
