4.23 Fluorescent Lamp Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-107
6. Remove the top case. Be careful not to apply excessive force to the top case or gate TCP.
Figure 4-94 Replacing 15.0 Inch LG.Philips fluorescent lamp (SXGA+) (2)
7. Remove the source PCB and gate PCB.
1) Remove the source PCB. Be careful not to apply excessive force to the PCB or
TCP when removing double-sided tape.
2) Remove the gate PCB. Be careful not to apply excessive force to the PCB or TCP
when removing double-sided tape.
Top case
