Appendix. C Pin Assignment Appendices

Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] C-29

C.32 CN4613 Parallel I/F Connector (25-pin)

Table C-32 Parallel I/F Connector pin assignment (25-pin)

Pin No. Signal name I/O Pin No. Signal Name I/O

1 STROB-P5N I 2 BPDB00-P5P I/O

3 BPDB01-P5P I/O 4 BPDB02-P5P I/O

5 BPDB03-P5P I/O 6 BPDB04-P5P I/O

7 BPDB05-P5P I/O 8 BPDB06-P5P I/O

9 BPDB07-P5P I/O 10 ACK-P5N I

11 BUSY-P5P I 12 PE-P5P I

13 SELCT-P5P I 14 AUTFD-P5N O

15 ERROR-P5N I 16 PINIT-P5N O

17 SLIN-P5N O 18 GND -

19 GND - 20 GND -

21 GND - 22 GND -

23 GND - 24 GND -

25 GND -

C.33 CN4620 USB harness I/F Connector (8-pin)

Table C-33 USB harness I/F connector pin assignment (8-pin)

Pin No. Signal name I/O Pin No. Signal Name I/O

1 USB signal4 - 2 USB signal2 I/O

3 USB signal3 I/O 4 USBPS-E5V I/O

5 USBPS-E5V I/O 6 N.C. -

7 N.C. - 8 GND -

C.34 CN4622 USB I/F Connector 1 (4-pin)

Table C-34 USB I/F Connector 1 pin assignment (4-pin)

Pin No. Signal name I/O Pin No. Signal Name I/O

1 USBPS-E5V I/O 2 USB signal2 I/O

3 USB signal3 I/O 4 USB signal1 I/O
