4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-75
5. Remove the panel assembly from the mold frame.
NOTE: When removing the panel assembly, be careful not to damage the COF.
Figure 4-57 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (5)
Panel assembly
Mold frame
