4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-79
9. Remove the lamp assembly from the mold frame.
Figure 4-61 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (9)
Lamp assembly
Mold frame
