Appendices Appendix. C Pin Assignment

C-24 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)

C.21 CN6002 Speaker Connector (Right) (2-pin)

Table C-21 Speaker connector (right) pin assignment (2-pin)

Pin No. Signal name I/O Pin No. Signal Name I/O

SPOUT(R+)

I 2

SPOUT (R-)

C.22 CN9500 Sound Board I/F Connector (18-pin)

Table C-22 Sound Board I/F connector pin assignment (18-pin)

Pin No. Signal name I/O Pin No. Signal Name I/O

1 A-GND - 2 A-GND -

3 A-GND - 4 LOUTL-PXP I

5 VROUTL-PXP O 6 A4R7-P4V I

7 A4R7-P4V I 8 VROUTR-PXP O

9 LOUTR-PXP I 10 A-GND -

11 HEADR-PXP I 12 HEADL-PXP I

13 SPKEN-P5P O 14 MMREFV-P2V O

15 MICIN-PXP O 16 A-GND -

17 A-GND - 18 A-GND -

C.23 CN8800 DC-IN Connector (4-pin)

Table C-23 DC-IN connector pin assignment (4-pin)

Pin No. Signal name I/O Pin No. Signal Name I/O

1 ADPDC O 2 PVDC O

3 PVH O 4 PVL O
