Replacement Procedures 4.23 Fluorescent Lamp
4-104 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
4. Stick the outside tape and install the cover shield.
1) Install the cover shield.
CAUTION: Wear anti-static gloves to prevent circuit damage to the source PCB.
2) Stick the adhesive tape to fix the top case and B/L wire.
Figure 4-92 Replacing 15.0 Inch LG.Philips fluorescent lamp (XGA) (8)
Cover shield
Adhesive tape
Adhesive tape
Adhesive tape
Cover shield
