4 Replacement Procedures 4.23 Fluorescent Lamp
4-72 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
4.23.1 Replacing the 15.0 Inch XGA Samsung Fluorescent Lamp
Disassembling the 15.0 Inch XGA Samsung Fluorescent Lamp
To disassemble the 15.0 inch XGA Samsung fluorescent lamp, follow the steps below and
refer to figures4-53 to 4-61.
1. Remove the PCB cover.
NOTE: When removing the PCB cover, be careful not to damage the COF.
Figure 4-53 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (1)
PCB cover
