4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-77
7. Remove the lamp back cover.
1) Remove the two screws from the lamp back cover.
2) Remove the lamp back cover.
Figure 4-59 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (7)
Lamp back cover
Screw
Screw
