4.23 Fluorescent Lamp Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-111
NOTE: Be careful not to apply excessive force to the PCB and TCP.
Figure 4-97 Replacing 15.0 Inch LG.Philips fluorescent lamp (SXGA+) (5)
Board assembly
Adhesive tape
Double-sided tape
Adhesive tape
Double-sided tape
Adhesive tape
Double-sided tape
Sheets and light guide
Adhesive tape
Screw
Cover assembly bottom (L)
Screw
Double-sided tape
